This RGBW Pixel strip combines smooth, dot-free illumination with SPI pixel control, making it ideal for dynamic architectural features, signage, and entertainment applications requiring animated lighting effects.

With a compact profile pixel strip delivers clean lines of light, soft diffusion, and excellent colour consistency across long runs.

Key Features

Top-view luminous output for continuous linear lighting
SPI control using USC2904 for pixel-based animation effects
Supports flowing, chasing, jumping, and gradient lighting effects
High-brightness SMD5050 LED chips
Uniform, shadow-free illumination with no visible LED hotspots
Soft, glare-free light suitable for close-view installations
Simple, modern exterior design for architectural integration
Durable silicone housing with excellent flexibility
Resistant to salt, corrosion, flame, and UV exposure

Optical & Control Design

The strip features a unique optical light-distribution structure to ensure even surface illumination, smooth RGBW colour mixing, and the complete elimination of visible spotting or shadowing.

The USC2904 SPI control enables individual pixel addressing, allowing complex animation effects and seamless integration into advanced lighting control systems.

Reliability & Environmental Performance

Backed by a 2-year quality warranty, with an expected working life of ~36,000 hours.

Specifications (24V DC Only)

Electrical

Input Voltage	24 V DC
Power Consumption	14.4 W/m
Operating Temperature	-25 deg to +60 deg

Light Source

LED Type	SMD5050
LED Density	84 LEDs per metre
Colour	RGBW
White CCT Options	3000 K
Luminous Output	Red: 78 lm Green: 175 lm Blue: 38 lm White: 245 lm

Pixel Control

IC Type	USC2904
Pixel Density	12 pixels per metre
Control Protocol	SPI
