This side-view RGBW LED neon strip delivers smooth, continuous lines of light with precise DMX control, making it ideal for architectural outlines, feature lighting, and dynamic entertainment applications.

With a compact flexible horizontal bending, and uniform surface illumination, this neon strip produces a soft, dot-free glow with excellent colour consistency across long runs.

Key Features

Side-view luminous output for clean linear and edge-lighting effects
Flexible left-right bending for curves and contours
DMX512 control using differential parallel signal protocol
Built-in anti-interference module for stable data transmission
High-brightness SMD5050 LEDs
Uniform, shadow-free illumination with no visible LED spotting
Soft, glare-free light suitable for close-view installations
High light-transmission, environmentally friendly silicone housing
Suitable for indoor and outdoor applications

Optical & Mechanical Design

The neon strip features a unique optical light-distribution structure that ensures even light output across the entire surface, eliminating dark zones and visible pixels while maintaining smooth RGBW colour blending.

The silicone jacket provides excellent flexibility while maintaining durability, making it suitable for both straight and curved installations.

Control & Performance

DMX512 protocol with differential parallel signal transmission
Enhanced resistance to electrical and signal interference
Consistent brightness across long runs, even when powered from a single end (up to 15 m)

Specifications

Electrical

Input Voltage	24 V DC
Power Consumption	19.2 W / m
Maximum Run Length	20 m
Operating Temperature	-25 deg to +60 deg

Light Source

LED Type	SMD5050
LED Density	60 LEDs per metre
Colour	RGBW
Luminous Output (per metre)	Red: 60 lm Green: 138 lm Blue: 40 lm White: 197 lm

DMX / Pixel Control

Pixel Density	10 pixels per metre
Control Options	DMX512

Physical

Dimensions	20m x 12 x 22 mm
Profile	Side-view neon
Bending Direction	Horizontal (left/right)
